型號 Type

名稱 Name

使用范圍 Usage range

MYQ-0.3/0.5

煤礦用移動輕型橡套軟電纜
Light movable rubber cover cable flexible cable for colliery

煤礦井下煤礦井下巷道照明，輸送機聯鎖和控制與信號設備的電源連接
Lighting of the lanes in the shft,interlocking of the conceyer and poer connection of control and signal

芯數×導體標稱截面(mm2)
Number of cores × nominal sectional area of theconductor

標稱厚度Nominal thickness

電纜外徑  Extecnal diameter of cable

絕緣Insulation

護套jacket

MYQ-0.3/0.5

2×1.0

0.6

1.5

8.10-8.90

2×0.5

0.8

1.5

9.40-10.3

2×2.5

1.0

1.5

11.5-12.7

3×1.0

0.6

1.5

8.40-9.01

3×1.5

0.8

1.5

9.90-10.9

3×2.5

1.0

1.5

12.1-13.4

4×1.0

0.6

1.5

9.10-10.1

4×1.5

0.8

1.5

10.7-11.8

4×2.5

1.0

2.0

14.3-15.7

7×1.0

0.6

1.5

10.6-11.7

7×1.5

0.8

2.0

13.6-15.0

7×2.5

1.0

2.0

16.8-18.4

12×1.0

0.6

2.0

14.6-16.0

12×1.5

0.8

2.5

18.3-20.1

12×2.5

1.0

2.5

22.7-24.9
