型號 Type

名稱 Name

用途 Usage

MY-0.38/0.66

煤礦用移動橡套軟電纜
Movable flexible rubber covered
cable for colliery

額定電壓為0.38/0.66kv各種井下移動采煤設備的電纜連接
Power connection of movable coal cutting equipments in the
Shaft with rated voltage of 0.38/0.66kv.

MYP-0.38/0.66

煤礦用移動屏蔽橡套軟電纜
Movable screening flexible rubber covered cable for colliery

額定電壓為0.38/0.66kv各種井下移動采煤設備的電纜連接
Power connection of movable coal cutting equipments in the
Shaft with rated voltage of 0.38/0.66kv.

MY-0.66/1.14

煤礦用移動屏蔽橡套軟電纜
Movable screening flexible rubber covered cable for colliery

額定電壓為0.66/1.14kv各種井下移動采煤設備的電纜連接
Power connection of movable coal cutting equipments in the
Shaft with rated voltage of 0.66/1.14kv.

芯數×導體標稱截面(mm2)
Number of cores × nominal sectional area of the conductor

標稱厚度
Nominal thickness

電纜外徑
Extemal diameter of cable

芯數×導體標稱截面(mm2)
Number of cores × nominal sectional area of the conductor

標稱厚度
Nominal thickness

電纜外徑
Extemal diameter of cable

絕緣
Insulation

護套
Jacket

MY-0.38/0.66

絕緣
Insulation

護套
Jacket

MY-0.38/0.66

1×50

1.6

2.4

18.7-20.5

1×185

2.2

3.4

32.7-35.9

1×70

1.6

2.6

20.9-23.0

1×240

2.4

3.5

35.3-38.8

1×95

1.8

2.8

24.2-26.6

1×300

2.6

3.6

40.0-43.3

1×120

1.8

3.0

26.4-29.0

1×400

2.8

3.8

43.4-47.7

1×150

2.0

3.2

30.1-33.1

1×500

3.0

4.0

45.6-49.8

芯數×導體標稱截面(mm2)
Number of cores × nominal sectional area of theconductor

標稱厚度
Nominal thickness

電纜外徑
Extemal diameter of cable

動力線芯
Dynamic core

地線芯
Grounding core

動力線芯絕緣
Dynamic core insulation

護套
Jacket

MY-0.38/0.66

MY-0.38/0.66

3×4

1×4

1.4

3.5

20.9-23.0

22.9-25.2

3×6

1×6

1.4

3.5

22.9-25.1

24.7-27.2

3×10

1×10

1.6

4.0

27.7-30.6

29.7-32.7

3×16

1×10

1.6

4.0

30.3-33.3

32.2-35.4

3×25

1×16

1.8

4.5

36.4-40.1

38.3-41.0

3×35

1×16

1.8

4.5

40.5-44.6

42.4-46.6

3×50

1×16

2.0

5.0

45.5-50.1

47.4-51.0

3×70

1×25

2.0

5.0

51.5-55.1

52.4-57.1

3×95

1×25

2.2

5.0

53.5-58.1

57.2-63.5

3×120

1×35

2.2

5.0

56.5-62.5

64.2-71.2

芯數×導體標稱截面(mm2)
Number of cores × nominal sectional area of theconductor

標稱厚度
Nominal thickness

電纜外徑
Extemal diameter of cable

動力線芯
Dynamic core

地線芯
Grounding core

動力線芯絕緣
Dynamic core insulation

護套
Jacket

MY-0.38/0.66

3×10

1×10

1.8

4.5

20.9-23.0

3×16

1×10

1.8

4.5

22.9-25.1

3×25

1×16

2.0

5.0

27.7-30.6

3×35

1×16

2.0

5.5

30.3-33.3

3×50

1×16

2.2

5.5

36.4-40.1

3×70

1×25

2.2

5.5

40.5-44.6

3×95

1×25

2.4

6.0

45.5-50.1

3×120

1×35

2.2

5.0

51.5-55.1
